PEW European Type Jaw Crusher | Vipeak Heavy Industry

PEW European Type Jaw Crusher is a next-generation, fully automatic hydraulic jaw crusher independently developed by Vipeak Heavy Industry. By integrating cutting-edge global mechanical engineering with the practical requirements of modern mining operations, this equipment addresses the common limitations of traditional jaw crushers, such as operational complexity, difficult adjustments, and high maintenance frequency.

Designed for intelligence, stability, and high throughput, the PEW series jaw crusher has become the primary crushing solution for high-efficiency, automated production lines in large- and medium-sized aggregate and ore processing sectors.

Key Applications

The PEW series is engineered for versatility and high performance across a variety of demanding environments:

Aggregate Processing: Sand and gravel pits, concrete batching plants.

Mining & Ore: Mineral processing, coal mining, metallurgical ore crushing.

Industrial Infrastructure: Road construction, water conservancy projects, power plant desulfurization.

Waste Recycling & Management: Construction waste recycling, dry-mixed mortar production, quartz stone processing.

Working Principle

The PEW European Type Jaw Crusher utilizes a motor to drive a flywheel, which activates the eccentric shaft, causing the swing jaw to move in a precise, elliptical path. As the swing jaw approaches the fixed jaw, raw material is crushed or split against the toothed jaw plates. When the swing jaw retracts, the crushed material is discharged through the bottom opening. This continuous, rhythmic cycle ensures high-volume throughput.

Performance Features

Structural Integrity

The bearing housing is constructed as a monolithic cast steel component, eliminating the structural stresses associated with split-housing designs. Combined with a heavy-duty forged eccentric shaft, this ensures maximum reliability and a longer service life under extreme loads.

Intelligent Hydraulic Control

Equipped with a dedicated hydraulic power unit, the crusher facilitates automated lubrication and rapid, safe chamber clearing. In the event of an overload or uncrushable material, the hydraulic system allows for quick clearance of the crushing chamber, significantly reducing unplanned downtime.

Optimized Crushing Efficiency

The "V"-shaped chamber and high-strength serrated liners are engineered to ensure the effective crushing surface area is maximized. This geometry prevents material bridging, increases capacity, and ensures consistent product sizing while significantly extending the wear life of the jaw plates.

Rapid Discharge Adjustment

Our advanced wedge-type discharge adjustment system allows operators to modify the closed-side setting (CSS) within minutes—even while the machine is idling. This system, paired with hydraulic automation, is safer, faster, and more precise than traditional shim-based systems.

Precision Manufacturing

Vipeak Heavy Industry utilizes state-of-the-art CNC machining centers for all structural components. From precision steel plate cutting and milling to automated surface finishing, our manufacturing process ensures that core components meet the highest industrial tolerances.

Comprehensive Lifecycle Support

As a direct manufacturer, Vipeak Heavy Industry provides full-lifecycle support. We offer comprehensive technical consultation, onsite installation guidance, and a reliable supply chain of genuine spare parts to ensure your equipment remains in peak condition.

Note: Capacities are based on a material bulk density of 1.6 t/m³. Specifications are subject to change due to ongoing product refinement. Please refer to our technical manual or contact the Vipeak representative for exact requirements for your project.
