Working Principle

When a XSD Sand Washer is working, driven by the motor, the impeller starts to rotate slowly under the coordinated action of triangular belt, reducer and gear. Sands and gravels enter the wash trough along with the feed trough where they, under the action of impeller, roll over and grind each other to remove impurities on the surface and to destroy the water vapor layer covering sands to facilitate dehydration. At the same time, add water to form a strong water flow to rinse away impurities and foreign matters. Clean sands and gravels are taken away by blades of the impeller and then poured into the discharge trough from the rotating impeller. This is the whole process of sand washing.

Performance

Large Capacity & Low Production Cost
The capacity of a XSD Sand Washer can reach 180t/h, which satisfies most sand washing requirements. The sand-washer is of small investment and low power consumption. So the production cost can be saved a lot.
Simple Structure & Low Failure Rate
The XSD Sand Washer is of simple and reasonable structure. The impeller drive bearing device is separated from the water and materials exposed to water. The new sealing structure and totally enclosed oil bath-type transmission device greatly avoid the occurrence of bearing damages caused by water soaking, sand and pollutants.
Multiple Functions---Washing, Dewatering And Grading
The XSD Sand Washer possesses washing, dewatering and grading functions. When working, the aggregate will grind mutually under the driving of impeller to remove the sundries covering on the aggregate surfaces and destroy the water vapor layer covering the sand. The XSD Sand Washer can also complete the washing and purifying functions under the effect of strong water flow.
Long Service Life & No Pollution
XSD Sand Maker has good structural layout and effective sealing design, allowing it to operate for a long term without maintenance (i.e., it is durable.). The water consumption is low and the operating noise is small which meet the national environmental protection standards.
