Working Principle

Vertical mill has two pairs of grinding rollers, each pair of roller composed of two narrow rollers, mounted on the same axis and can rotate at different speeds. There are two circular disc slot, and roller to the tire shape, work pressure in the tank. Disc roller and the relative sliding velocity between small and roller can swing, even if the roller sleeve and the disc after the liner wear can guarantee a good abrasive, will not affect the grinding effect. Roller symmetrical structure, one side can be upside down after use and wear. Material grinding process: hydraulic pneumatic roller device through the pressure applied to the material on the crushing of materials, the materials have been moved to crush the edge of disc, from the disc around the nozzle from the exhaust air to improve these materials to Separator.Meal to separate returns after a concentrated mill, fine powder was collected in the precipitator unloading. In the gas flow is small, the meal can not be increased to enhance air flow, they would fall through the nozzle discharged outside the mill, bucket elevator to be transported to the feeder of vertical mill and was re-grinding mill feed people.

Performance

Less Comprehensive Investment
LM Vertical Grinding Mill integrates crushing, drying, grinding, separating and transport. The structure is simple while the layout is compact. Its occupational area is about 50% of that of the ball-milling system. The LM grinding mill can also be arranged outdoors, which greatly reduces the investment cost.
Comprehensive Optimization, Lower Operating Costs
From aspects of grinding efficiency, powder drying, abrasion of vulnerable parts and maintenance & replacement of spare parts, Vipeak's LM Vertical Grinding Mill achieves lower energy consumption, stronger drying capacity, as well as lower abrasion and easier checks of core parts, saving the operating costs greatly.
Short Grinding Time & Low Iron Content
The materials linger in the grinding mill for a short time, which can reduce repeated grinding and is easy to detect and control the grain size and chemical component of the product. In addition, the grinding roller and millstone do not contact directly. The iron content in the product is very low, and the iron generated due to mechanical wear is easy to be removed, thus effectively guaranteeing the whiteness and purity of the material.
Greener & More Automated
The operation of LM grinding mill is stable and has small vibration, so that the noise is small. The system is sealed in an integral manner and works under negative pressure, so that there is no dust spilling and the environment can keep clean with the emission standard far better than the international standard. LM grinding mill is also equipped with expert-level automatic control system, which can realize free switch between remote control and local control. The operations are simple and labor-saving.
Digitalized Processing, Higher Precision
There are tens of lines of numerical controlling machine tools. Operations such as steel plates' cutting, bending, planing, milling and paint spraying are all controlled numerically. The machining precision is high, especially for the core parts.
